Tapered roller bearings instructions：
Tapered roller bearings are mainly used to bear the radial load based on the radial and bearing joint load, generally should not be alone to bear the axial load, the kind of bearings can be installed in the inner ring, respectively.
(with a full set of roller and cage) and outer ring.
The bearing does not allow the shaft to be tilted relative to the shell, and the additional axial force can be generated under the action of the radial load. The bearing axial clearance of the size of the bearing can work.
The Department is large, when the axial clearance is too small, high temperature rise; the axial clearance is large, easy to damage the bearing. So in the installation and operation should pay special attention to the bearing axial clearance
, when necessary, can be pre installed, to increase the rigidity of the bearing.
Single row tapered roller bearings are mainly used to bear radial load mainly in the radial and axial joint load, generally should not be alone to bear the axial load.
The bearing limit shaft or shell side axial displacement, does not allow the tilt axis relative shell hole. The bearing in the radial load is used to generate additional axial force, so the general
In the two bearing of the shaft, the outer ring of the bearing and the inner ring of the bearing should be in accordance with each other.
Clearance of the bearing, according to different requirements, the user adjust the installation.
